HOME> PRODUCTS> Concrete Mixer Truck> HM16-D Concrete Mixer Truck 9m³

HM16-D Concrete Mixer Truck

Download Product Manual (PDF file)
wade@haomei.biz Get samples and prices !

Cut to size at customers' need !

Add to Product Favorites
Share
Product Overview

HM16-D Concrete Mixer Truck is used to transport concrete; The concrete mixer truck are cylindrical device on the mixing tube to carry the ready mixed concrete. During transport the concrete mixer truck will always keep stirring drum rotation to ensure the delivery of concrete not to be solidified. After finishing delivering the concrete, the operator usually rinse inside the mixing tube to prevent hardening of concrete space.

Model

HM16-D

Specification

Value

Mixing Capacity

16m³

Tank Volume

24.1m³

Feeding Speed

≥3.5m³/min

Discharging Speed

≥3m³/min

Residual Ratio of Discharging

≤0.5%

Water Supply System

Air pressure

Water Tank Volume

400L

Overall Dimension

10850*2496*3980mm

Chassis Model

HOWO

Clutch

φ430 Monolithic dry type

Min Ground Clearance

245mm

Max Speed

90km/h

Engine Max Output Power

340kw

Emission Standard

Euro Ⅲ

Rated Load

16600kgs

Overall Weight

31000kgs

Wheelbase

1800+3600+1350mm



Features

1. High-intensity drum material, featuring better wear-resistance and long service life;
2. Optimized mixing blades, low material residue;
3. High-quality parts, reliable running;
4. Excellent performance and convenient operation;
5. Imported original hydraulic system

Applications

Wide range of application especially for mass concreting works like Construction of Canals, Bridges, Highways, Dams, Multistoried & Industrial Buildings, Factories, and Airports for ready mixed concrete works.

Why Choose Haomei Machinery.
  • Technologies:Top polishing technology guarantees good luster and smooth surface.
  • Markets:Obtain market sharing all over the world.
  • Equipment:Advanced cutting line to provide a wide range of specifications.
  • Production capacity:25 to 180m3/h.can be customized to meet any demand of the products raised by our customers.
  • Employees:Over 25 sale persons to provide good service for customers.
  • Responsibility: Engaged in charity donation and provide eco-friendly products.
Packaging and Delivery of Haomei.

1. Standard seaworthy container 20 GP or 40 GP ,40 HQ according to configuration ;
2. With wires for fastening the machine and frame structure inside the container ;
3. The electric items and installation components packed with strong and standard packages.

  • Concrete-plant Packaging
  • Concrete-plant Packaging
  • Concrete-plant Packaging
  • Concrete-plant Packaging
