YHZS50 Mobile Concrete Batching Plant

Download Product Manual (PDF file)
wade@haomei.biz Get samples and prices !

Cut to size at customers' need !

Add to Product Favorites
Share
Product Overview

YHZS50 modular mobile concrete mixing plant is special construction concrete equipment designed by our company as module. It is applied for airport way, wharf, road, bridge and so on, It can also be used for the large and emergency repair construction operation. It can be installed quickly on site. This mixing plant is consisted by mixer, batching system, feeding system, weighing system, cement silo, screw conveyor and all the necessary equipment, and they are designed as module .So We can deliver YHZS series concrete plant easily by container, and install quickly on site and get it to run without debugging. This equipment has the characteristic of high automatic, well mixing, high productivity, high flexibility, convenient operation, and good stability.
This series of mixing plant adopts the semi-pulling structure with running system and standard coupling pin included. It can be dragged by trailer. Without foundation and commissioning enables convenient transportation, the mixing plant can be divided into several standard modules, and then be packed into containers.

YHZS50
Theoretical production capacity(m³/h) 50
Concrete mixer Type JS1000
Power(KW) 51
Discharging capacity(L) 1000
Aggregate size(Pebble/Macadam)(mm) 80/60
Aggregate Bin volume(m³) 8.3
Weighing Accuracy Aggregate (KG)  ±2%
Cement(KG) ±1%
Fly ash(KG) ±1%
Water (KG) ±1%
Additive(KG) ±1%
Total power(KW) 85Kw
Discharging height(M) 2.8 m
Gross weight(T) 20



Drawing YHZS50 Concrete Batching Plant Drawing Features

1. More secure: layout and installation of electrical wiring fully considers safety. Many places are equipped with safety switch.
2. More reliable: Professional embedded computer, which can be operated manually, automatically and automatic production which will meet a variety of needs. And the control system has the data backup function at sudden power outage which can effectively prevent data destruction.
3. More powerful: Automatic storage management can record operational process. And automatically maintenance warning system can remind operators.

Applications

YHZS50 mobile concrete batching plants are widely used in various kinds of large and medium scale prefabricated factory, construction site, road, bridge, airport, tunnel and many other projects. It is also suitable for water conservancy, the electric power, the railroad, the road, the harbor-wharf and so on.

Why Choose Haomei Machinery.
  • Reliability: 20 years of experiences in manufacturing concrete batching plants;
  • Markets:Obtain market sharing all over the world.
  • Equipment:Advanced cutting line to provide a wide range of specifications.
  • Production capacity:25 to 180m3/h.can be customized to meet any demand of the products raised by our customers.
  • Employees:Over 25 sale persons to provide good service for customers.
  • Responsibility: Engaged in charity donation and provide eco-friendly products.
Packaging and Delivery of Haomei. packing and shipping Mobile concrete batching plant

1. Standard seaworthy container 20 GP or 40 GP ,40 HQ according to configuration ;
2. With wires for fastening the machine and frame structure inside the container ;
3. The electric items and installation components packed with strong and standard packages.

FAQ
  • What is the price of a Mobile batching plant?
    Just like buying a custom computer, a quotation can only be issued after all the configurations are confirmed. By telling us the configuration you need, or the use scene, you will get a detailed quotation list in 24 hours.
  • How much will it cost for the Mobile concrete plant to be delivered?
    Before your equipment is ordered, you should know the totals for what it will cost, including freight and insurance, to have all the equipment delivered to your exact address or shipping port. We need to specify the exact equipment you are considering for purchase in detail before providing you a freight offer. You would normally obtain an exact freight offer after you have visited me or have seen the equipment in operation. We don’t provide freight quotes until we both know exactly what you need and have been quoted on equipment.
  • what range size cement Silos you supply?
    The regular size is 30T- 300T, and the biggest Bolted Type Silos can up to 1500T .
  • What kind of spare parts you supply?
    All Batching plant parts, including mechanical processing parts, mixer wearing parts, pneumatic fittings, load cell, belt conveyor parts, roller, motors, bearings, electrical elements & cables, switch board and so on
  • What should I do if experiencing a problem on our batching plant?
    Please email or call us what it happen, show us the symptom details and photos, then our engineer will guide you how to cover it. Our service line will be on line 24/7/365.
